Non-Inverting-II Tubes

Description

The non-inverting 18 mm image intensifier tube is a hermetically sealed unit featuring a microchannel electron multiplier plate with proximity-focused input and output. It integrates a high-voltage power supply, automatic brightness control, and over-light protection for stable, high-quality imaging.
Equipped with a multialkaline photocathode and a phosphor screen (available in yellow-green or black & white emission) on a fiber-optic output element, it delivers clear visuals even under extremely low light conditions.

Specifications:
Emission: Green / Black & White
Diameter: 43 mm
Resolution: 57 lp/mm
SNR: 18–30
Photocathode Sensitivity (at 2850 K): 500–1000 µA/lm
